Neural DSP Nano Cortex Digital Effects Processor and Profiling Pedal
Neural DSP Nano Cortex Digital Effects Processor and Profiling Pedal
DESCRIPTION
Nano Cortex delivers studio-grade sound, a fully customizable signal chain, a complete suite of effects, and the revolutionary Neural Capture technology - all in a compact, ultra-portable pedal. Whether you’re on stage, in the studio, or anywhere in between, your perfect tone is always within reach.
Since its release, Neural Capture has transformed how players approach tone, delivering unmatched accuracy in capturing and replicating amps, cabs, and drive pedals. Artists and engineers alike have praised how real and responsive it feels to play.
Now, that same groundbreaking technology is packed into a travel-ready unit built for real-world use - wherever inspiration strikes.
Welcome to the future of portable, professional-grade tone.
SPECS
Dimensions: 14.4 × 10.3 × 6.2 cm (5.6 × 4.0 × 2.4 in)
Weight: 1.36 lbs
Processor: SHARC DSP (2 GHz)
Inputs / Outputs
-
¼″ instrument input (1 MΩ)
-
XLR/¼″ combo input with +26 dB boost option
-
Dual ¼″ TRS main outputs (balanced/unbalanced)
-
3.5 mm headphone out with volume control
-
USB-C (audio interface, 24-bit / 48 kHz, 4 in / 3 out)
-
TRS MIDI / expression input
-
Bluetooth for app control
Power
-
9–12 V DC, 600 mA (center negative)
-
USB-C (5 V, ≥1.5 A)
Storage & Presets
-
256 Neural Capture slots
-
256 IR slots (10 premium preloaded)
-
64 user presets
Effects & Signal Chain
-
Fixed layout with 7 blocks: input gate, 2 pre-FX, capture, IR loader, 3 post-FX
-
50+ effects (drives, compression, EQ, modulation, delay, reverb, utility)
-
Global cab bypass option
Library
-
20 guitar amp captures, 5 bass amp captures, drive pedals
-
8 guitar cabs + 2 bass cabs with mic models and positions
Workflow & App
-
Works standalone (no app required)
-
Amp/pedal captures take ~5 minutes on-device
-
Cortex Cloud app via Bluetooth for presets, captures, firmware, and sharing
HEAR A LIVE DEMO
Experience our innovative Video Appointment service! Connect with our Gear Experts to hear this instrument played live ov
Original: $569.00
-70%$569.00
$170.70
